Design

Dimensions

  • Dimensions: 74.3 x 66.44 x 16.85 mm
  • Weight (with battery): 129 g
  • Volume: 76 cc
  • Additional size and shape information:
  • Slide form factor

Display and user interface

  • Size: 2.36″
  • Resolution: 320 x 240 pixels QVGA 2.4” TFT display in  16 million colors
  • Up to 262,000 colours, 18-bit colour
  • Landscape
  • Torch light
  • Accelerometer
  • Internal vibra

Keys and input methods

  • Slide-out QWERTY keyboard
  • Media key for quick music player access
  • 4-way Navi™ key
  • Call and end keys
  • Home key

Colours

  • Available colours:
    • Graphite Black
    • Pink

Personalisation

  • Customisable home screen:
    • Themes
    • Icons
    • Shortcuts
    • Menu
  • Customisable profiles
  • Ringtones: MP3, AAC, eAAC+, polyphonic 64 voices, video
  • Themes
    • wallpapers
    • screensavers
    • ringtones
    • pre-installed themes
    • changeable colour themes


Hardware

Power Management

  • BL-5F 950 mAh Li-Ion battery
  • Talk time (maximum):
    • GSM (band 850) up to 4 h
    • GSM (all other bands) up to 5 h
    • 3G up to 3 h 30 mins
  • Standby time (maximum):
    • GSM up to 400 h
    • 3G up to 400 h
  • Music playback time: up to 30 h

Operation times may vary depending on radio access technology used, operator network configuration and usage.

Memory

  • MicroSD memory card slot, up to 32 GB
  • 2 GB microSD card supplied in box
  • Internal memory: 200 MB

Operating frequency

  • Quad-band EGSM 850/900/1800/1900 3GPP Rel. 5
  • WCDMA 850/1900/2100 or 900/1900/2100
  • Automatic switching between GSM bands
  • Flight mode

Data network

  • EDGE multi-slot class 32, maximum speed 296 kbps downlink
  • GPRS multi-slot class 32, maximum speed 100 kbps downlink
  • HSDPA category 9, maximum speed 10.2 Mbps downlink
  • HSUPA category 5, maximum speed 2 Mbps uplink
  • WLAN 802.11b/g

Requires data service. Data Services may not be available in all networks. Data transmission speeds may be as high as 10.2 Mbps, but may vary based upon network capabilities and other conditions. The establishment and continuation of a data connection depends on network availability, provider support and signal strength.

Connectivity

  • Stereo Bluetooth version 2.1 with Enhanced Data Rate and Advanced Audio Distribution Profile (A2DP)
  • High-speed microUSB 2.0 connector
  • Support for local and remote SyncML synchronisation
  • 3.5 mm AV connector
  • USB charging


Software & Applications

Software platform & user interface

  • S60 3rd edition release 3.2.3
  • Voice commands
  • FOTA (firmware update over the air)
  • Software updates

Applications

  • Nokia Messaging 2.0 for email and chat
  • Ovi Suite 2.0/2.1 for syncing with computer
  • Ovi Contacts 2.0 for backing up contacts and social networking
  • Ovi Store support on phone to get more apps
  • Ovi Mail free email account with 1 GB storage
  • Facebook
  • Myspace
  • Hi5
  • Shazam
  • Surprise me! plays random tracks
  • Playlist DJ for playlists to match your mood
  • Message Box lets you hear the number of unread messages

*Some services dependent upon sales region and may only be available via downloading or upgrading.

Personal Information Management (PIM)

  • Detailed contact information
  • Calendar
  • To-do list
  • Notes
  • Recorder
  • Calculator
  • Clock
  • Converter


Communications

Email and messaging

  • Easy-to-use email client with attachment support for images, videos, music, and documents
  • Supported for SMTP, IMAP4, POP3, MMS, SMS. Unified MMS/SMS editor
  • Nokia Xpress audio messaging
  • Instant messaging through Windows Live Messenger™, Yahoo!® Messenger, Google Talk™ and Ovi Chat

Call management

  • Contacts: advanced contacts database with support for multiple phone and e-mail details per entry and thumbnail pictures
  • Speed dialling, voice dialling (speaker independent) and voice commands
  • Logs of dialled, received and missed calls
  • Conference calling
  • Integrated handsfree speakers


Sharing & Internet

  • Full web browsing of web pages
  • WAP 2.0, XHTML browser over HTTP/TCP/IP stack


Photography

Camera

  • 5 megapixel camera
  • Full focus
  • LED Flash
  • Zoom up to 4x (digital)

Other

  • 200 MB internal memory, with support for up to 32 GB additional memory with microSD card
  • High-speed USB 2.0 connectivity
  • Bluetooth 2.1 EDR wireless connectivity


Video

Video camera

  • Video capture in VGA at up to 15 fps

Video codecs & formats

  • MPEG-4, VGA at up to 15 fps
  • Video file format: .mp4 (default), .3gpp (H.263)


Music & audio

Music features

  • Music player for mp3, AAC, AAC+, eAAC, WMA, DAC 33 audio chip
  • Ovi Music Store support
  • Shazam identifies songs you don’t recognise
  • Surprise me! plays random tracks
  • Playlist DJ for playlists to match your mood
  • Integrated speaker

Radio

  • Stereo FM radio (87.5-108 MHz/76-90 MHz), RDS
  • Internet Radio


Gaming

  • Preloaded games, dependent upon sales region
  • Additional games available at Ovi Store


Environmental features

  • Power Save mode, ambient light sensor, unplug charger reminder


Package contents

Standard Sales Package

  • Nokia X5-01
  • 50 track music voucher
  • Nokia BL-5F 950 mAh Li-Ion battery
  • Nokia Travel Charger AC-6N
  • Nokia 2 GB microSD card MU-37
  • Nokia Connectivity Cable CA-101D
  • Nokia Headset WH-102
  • Compact User Guide

Nokia X5-01 - 2010
