Dimensions

• Height : 130.3  mm
• Width : 70.8  mm
• Thickness : 10.7  mm
• Weight : 185  g
• Volume : 99  cm³

Form factor

• Monoblock

Display and User Interface

• Display size : 4.5”
• Screen height : 1280  pixels
• Screen width : 768  pixels
• Display colors : 16.7 million
• Display technology : PureMotion HD+

Display features

• Polarization filter
• Light time-out
• Ambient light detector
• Brightness control
• Orientation sensor
• Sculpted 2.5D glass
• Proximity sensor
• High Brightness mode
• RGB Stripe
• Sunlight readability enhancements
• Pixel density 332 ppi
• Luminance 600 nits
• Aspect ratio 15:9
• Corning® Gorilla® Glass
• Super sensitive touch
• Color boosting
• IPS
• Refresh rate 60 Hz

User Input

• Touch

Dedicated hardware keys

• Windows Start key
• Camera
• Power
• Volume
• Search
• Back

Hardware

Connectivity

Dual SIM

• No

Connectors

• Micro-USB Charging Connector
• Micro-USB Data Connector
• 3.5 mm Universal Audio Connector
• Micro-USB 2.0

SIM card type

• Micro SIM

Wireless connectivity

• Near Field Communication
• Bluetooth 3.1
• Wi-Fi Direct
• Wi-Fi Channel bonding
• WLAN IEEE 802.11 a/b/g/n
• Qi Wireless charging

Syncronization

• Windows computer companion application
• Mac computer companion application
• Exchange ActiveSync

Data synchronization

• Calendar, Contacts, To-Dos via Outlook
• Transfer Media (Music, Video, Photos) to your computer

WLAN features

WLAN security

• WPA2 (AES/TKIP)
• WPA
• WEP
• PEAP-MSCHAPv2
• EAP-SIM
• EAP-AKA

Memory

• Internal memory : 1000  MB
• Mass memory : 32GB and 7GB in SkyDrive

Data Network

Data bearers

• HSPA+ (3G)
• EDGE/EGPRS (2G)
• FD-LTE (4G)
• HSUPA (3G)
• GSM (2G)
• HSDPA (3G)
• WCDMA (3G)
• Dual Transfer Mode (2G)

Power Management

• Battery model : BP-4GW
• Battery capacity : 2000  mAh
• Battery voltage : 3.7  V
• Removable battery : No
• Maximum 2G standby time : 400  h
• Maximum 2G talk time : 17  h
• Maximum 3G standby time : 400  h
• Maximum 3G talk time : 10  h
• Maximum music playback time : 67  h
• Maximum video playback time : 6  h
• Maximum video recording time : 3 h

Operating Frequency

Bands

• GSM 850
• GSM 900
• GSM 1800
• GSM 1900
• WCDMA Band V (850)
• WCDMA Band VIII (900)
• WCDMA Band II (1900)
• WCDMA Band I (2100)
• LTE 800
• LTE 900
• LTE 1800
• LTE 2100
• LTE 2600

Data speed – Upload

• HSUPA Cat 6 – 5.76 Mbit/s
• LTE Cat 3 – 50 Mbit/s

Data speed – Download

• EGPRS MSC 12 – 236.8 kbit/s
• LTE Cat 3 – 100 Mbit/s
• HSDPA Cat 24 – 42.2 Mbit/s

Processor

• Processor name : Snapdragon™ S4
• Processor type : Dual-core 1.5Ghz

Snapdragon™ S4 Processor

Performance

Do more. Wait less

Tap into faster performance. The Snapdragon™ processor CPU cores enable extra performance when you need it and puts you in charge of running the most demanding applications, including gaming, photography, as well as business and personal productivity.

Power consumption

Less charging. More doing

The Snapdragon™ processor’s unique asynchronous technology enables each core to power up and power down independently, resulting in maximizing core performance level without wasting battery power.

Technology

Beyond mobile. And beyond all expectations

Snapdragon™ S4 processor is a highly integrated, mobile-optimized system on a chip that delivers dynamic, immersive experiences and powerful, battery-friendly performance that can put new possibilities in your hands.

Software and applications

Personal Information Management (PIM)

Personal information management features

• Recorder
• Calculator
• Clock
• Calendar
• Phonebook
• Notes
• Reminders
• To-do list
• Phonebook with integrated social networks
• OneNote
• Wallet

Other Applications

Phonebooks

• One integrated Phonebook

Software updates

• Over the air

Business Productivity

• Office Applications (Excel, Word, Powerpoint, One Note)
• SkyDrive storage for documents and notes
• Lync available as free download

Software platform & User Interface

Operating system

• Windows Phone 8

Development technology

• Silverlight
• XNA
• Visual Basic
• DirectX
• Java Script
• C++
• XAML

Communications

Email and Messaging

Email solution

• Yahoo! Mail
• IBM Lotus Traveler
• Windows Live / Hotmail / Outlook.com
• Gmail
• Mail for Exchange
• Office 365
• Nokia Email

Email protocols

• SMTP
• IMAP4
• POP3

Email features

• Viewing and editing of email attachments
• Email with filtering
• Always up to date
• Multiple simultaneous email accounts
• HTML email
• Text-to-speech message reader
• Email attachments
• Conversational view on email
• Linking multible inboxes to one

Supported instant messaging services

• Twitter
• Facebook chat
• LinkedIn
• Windows Live Messenger

Document format

• PDF
• Powerpoint
• Excel
• Word

Call management

Call management features

• Voice dialling
• Voice commands
• Conference calling
• Video calling
• Voice mail
• Video sharing
• Integrated hands-free speaker
• HD audio

Contacts

• Unlimited

Device security

Security

Enterprise security features

• Remote security policy enforcement

Device startup security

• Device passcode
• Secure device start-up
• PIN code
• Firmware and OS integrity check

Advance security features

• Lost device tracking
• Anti-phishing protection

Data encryption

• User data encryption for device

Sharing and Internet

Browsing and Internet

Internet sharing

• Use as a Wi-Fi Hotspot for up to 5 Wi-Fi-enabled devices

Supported web technologies

• XML
• CSS 3
• HTML 5
• HTML 4.1
• CSS

Browser

• Internet Explorer 10

Navigation

GPS and navigation

Navigation features and services

• Nokia Maps
• Nokia Drive: route optimization
• Nokia City Lens
• Nokia Transport
• Offline maps
• Turn-by-turn voice guided navigation

Positioning features

• Magnetometer
• A-GPS
• WLAN Network Positioning
• Glonass
• Speed limit warnings
• Online and offline favorites

Photography

Main camera

• Camera sensor (main camera resolution) : 8.7  megapixels
• Camera flash type : Short pulse high power dual LED
• Carl Zeiss Tessar lens : Yes
• Camera resolution : 3264 x 2448 pixels
• Camera focus type : Auto focus with two-stage capture key
• Camera F number/aperture : 2.0
• Camera digital zoom : 4  x
• Camera focal length : 26.0  mm

Secondary camera

• Secondary camera resolution : 1280 x 960 pixels

Main camera features

Camera features

• Nokia PureView camera
• Touch focus
• Landscape orientation
• Geo-tagging
• Auto and manual white balance
• Still image editor
• Optical Image Stabilization
• Lenses applications
• Sensor size 1/3 inch
• Sensor type: BSI
• True 16:9 sensor
• Pixel size 1.4 µm

Camera image formats

• JPEG/Exif

Image capturing

Flash modes

• Off
• Automatic
• On

Capture modes

• Video
• Still

White balance modes

• Cloudy
• Tungsten
• Fluorescent
• Daylight

Photos viewed by

• Camera Roll
• Timeline
• Photo editor
• Favorites
• Album
• Photos from Social networks

Music and Audio

Music

Music package

• Nokia Music Store
• Nokia Mix Radio

Noise cancellation

• Multimicrophone noise cancellation

Audio recording features

• Mono with high volume capture

Music features

• Dolby Headphone
• Music Player
• Media Player
• Audio Streaming

DRM support

• PlayReady

Music format

Codecs

• MP3
• AMR-WB
• AMR-NB
• WMA 10 Pro
• WMA 9
• AAC LC
• AAC+/HEAAC
• eAAC+/HEAACv2

Audio playback file formats

• ASF
• WAV
• MP4
• AAC
• AMR
• MP3
• M4A
• WMA
• 3GP
• 3G2

Voice and audio recording

Audio recording format

• AMR

Recording

• Voice commands

Audio recording codecs

• AMR-NB

Speech codecs

• AMR-WB
• GSM FR
• AMR-NB
• GSM HR
• EFR

Video

Main video camera

• Video camera resolution : 1920 x 1080 pixels
• Camera video frame rate : 30  fps
• Camera video zoom : 4  x
• Video white balance modes
  • Cloudy
  • Fluorescent
  • Tungsten
  • Daylight

Secondary video camera

• Secondary video camera resolution : 1280 x 720 pixels

Main video camera features

Video streaming

• YouTube browsing and video streaming

Video features

• Video recorder
• Video call
• Video sharing
• Video player

Video codecs & formats

Video playback codecs

• VC-1
• H.264/AVC
• H.263
• MPEG-4

Video playback formats

• MP4
• WMV
• 3GP
• M4V
• M4A

Other features (video)

Video sharing and playback

• Video sharing to social network
• Share with DLNA compatible TV with an application
• Video sharing to Facebook
• Video sharing with NFC
• Video sharing to Skydrive

Environment

Environmental features

Packaging

• Made of renewable materials
• Containing up to 60% recycled materials
• Minimized package
• Packaging is 100 % recyclable
• Virgin wood fibres up to 100% certified

Materials

• Free of BFR, rFR as in Nokia Subst. List
• Free of PVC
• Contains recycled metals
• Free of nickel on the product surface

Product is recyclable up to

• 100% recoverable as materials and energy

User guide

• Small printed guide, full on nokia.com
• In-device user guide

Sales Package

• Nokia Lumia 920
• Nokia Fast USB Charger AC-16
• Battery BP-4GW 2000 mAh
• Nokia Charging and Data Cable CA-190CD
• Nokia Headset WH-208
• Quick guide
